| Product characteristics | |||
|---|---|---|---|
| Number of inputs and outputs | Number of digital outputs: 2 | ||
| Measuring range |
|
||
| 0…250 bar | 0…25 MPa | ||
| Process connection | threaded connection G 1/4 external thread internal thread:M5 | ||
| Electrical data | |||
| Operating voltage [V] | 9.6…32 DC | ||
| Current consumption [mA] | < 25 | ||
| Min. insulation resistance [M?] | 100; (500 V DC) | ||
| Protection class | III | ||
| Reverse polarity protection | yes | ||
| Mechanical data | |||
| Weight [g] | 96 | ||
| Materials | PBT; PC; FKM; stainless steel (1.4404 / 316L) | ||
| Materials (wetted parts) | stainless steel (1.4404 / 316L); FKM | ||
| Min. pressure cycles | 50 million | ||
| Tightening torque [Nm] | 25 | ||
| Process connection | threaded connection G 1/4 external thread internal thread:M5 | ||
| Restrictor element integrated | no (can be retrofitted) |
