| Product characteristics | ||||
|---|---|---|---|---|
| Number of inputs and outputs | Number of digital outputs: 2; Number of analogue outputs: 1 | |||
| Measuring range |
|
|||
| 0…250 bar | 0…3625 psi | 0…25 MPa | ||
| Process connection | threaded connection G 1/4 internal thread | |||
| Electrical data | ||||
| Operating voltage [V] | 18…30 DC; (to SELV/PELV) | |||
| Current consumption [mA] | < 35 | |||
| Min. insulation resistance [M?] | 100; (500 V DC) | |||
| Protection class | III | |||
| Reverse polarity protection | yes | |||
| Power-on delay time [s] | 0.3 | |||
| Integrated watchdog | yes | |||
| Mechanical data | ||||
| Weight [g] | 280.5 | |||
| Materials | stainless steel (1.4404 / 316L); PBT+PC-GF30; PBT-GF20; PC | |||
| Materials (wetted parts) | stainless steel (1.4404 / 316L); Al2O3 (ceramics); FKM | |||
| Min. pressure cycles | 100 million | |||
| Tightening torque [Nm] | 25…35; (recommended tightening torque; depends on lubrication, seal and pressure rating) | |||
| Process connection | threaded connection G 1/4 internal thread | |||
| Restrictor element integrated | no (can be retrofitted) |
