| Product characteristics | |||||
|---|---|---|---|---|---|
| Measuring range |
|
||||
| 0.3…15 l/min | 0.018…0.9 m³/h | 4.8…237.8 gph | 0.08…3.965 gpm | ||
| Process connection | threaded connection G 3/4 internal thread | ||||
| Electrical data | |||||
| Operating voltage [V] | 18…30 DC; (according to EN 50178 SELV/PELV) | ||||
| Current consumption [mA] | < 50 | ||||
| Protection class | III | ||||
| Reverse polarity protection | yes | ||||
| Power-on delay time [s] | < 3 | ||||
| Mechanical data | |||||
| Weight [g] | 994 | ||||
| Materials | stainless steel (1.4404 / 316L); PBT+PC-GF30; PBT-GF20; PC; brass chemically nickel-plated | ||||
| Materials (wetted parts) | stainless steel (1.4401 / 316); stainless steel (1.4404 / 316L); brass (2.0371); brass chemically nickel-plated; PPS; O-ring: FKM | ||||
| Process connection | threaded connection G 3/4 internal thread | ||||
| Switching cycles mechanical | 10 million | ||||
| Electrical connection | |||||
| Connection | Connector: 1 x M12; Contacts: gold-plated |
