| Display | |
| Display | 10.1” TFT |
| Resolution | 800 x 480 |
| Brightness (cd/m2) | 300 |
| Contrast Ratio | 500:1 |
| Backlight Type | LED |
| Backlight Life Time | >30,000 hrs. |
| Colors | 262K |
| Touch Panel | |
| Type | 4-wire Resistive Type |
| Accuracy | Active Area Length(X)±2%, Width(Y)±2% |
| Memory | |
| Flash | 128 MB |
| RAM | 128 MB |
| Processor | 32-bit RISC 600MHz |
| I/O Port | |
| SD Card Slot | N/A |
| USB Host | USB 2.0 x 1 |
| USB Client | N/A |
| Ethernet | 10/100 Base-T x 1 |
| COM1: RS-232 4W | |
| COM Port | COM2: RS-485 2W/4W |
| COM3: RS-485 2W | |
| RS-485 Dual Isolation | N/A |
| CAN Bus | N/A |
| HDMI | N/A |
| Audio Output | N/A |
| RTC | Built-in |
| Power | |
| Input Power | 24±20%VDC |
| Power Isolation | Built-in |
| Power Consumption | 400mA@24VDC |
| Voltage Resistance | 500VAC (1 min.) |
| Isolation Resistance | Exceed 50MW at 500VDC |
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| Specification | |
| PCB Coating | Yes |
| Enclosure | Plastic |
| Dimensions WxHxD | 271 x 213 x 40 mm |
| Panel Cutout | 260 x 202 mm |
| Weight | Approx. 1.3 kg |
| Mount | Panel mount |
| Environment | |
| Protection Structure | NEMA4 / IP65 Compliant Front Panel |
| Storage Temperature | -20° ~ 60°C (-4° ~ 140°F) |
| Operating Temperature | 0° ~ 50°C (32° ~ 122°F) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| Certificate | CE marked |
| Software | |
| EasyBuilder Pro | V4.10.04 or later versions |
| Weincloud | EasyAccess 2.0 (Optional) |
