| Product characteristics | |
|---|---|
| Number of inputs and outputs | Number of digital outputs: 1 |
| Electrical data | |
| Operating voltage [V] | 18…30 DC; (on the master side; on the controller / system: 20…30 DC) |
| Nominal voltage DC [V] | 24 |
| Current consumption [mA] | < 17; (both sides) |
| Protection class | III |
| Reverse polarity protection | yes; (on the master side) |
| Power-on delay time [s] | < 2; (for communication; response time switching signal: response time device plus IO-Link process cycle time) |
| Mechanical data | |
| Weight [g] | 90 |
| Materials | stainless steel (1.4404 / 316L); brass (2.0401); PBT; PA; Sealing: FKM; |
| Electrical connection – plug | |
| Connector: 1 x M12; Contacts: gold-plated |
