| Product characteristics | |
|---|---|
| Number of inputs and outputs | Number of digital outputs: 1; Number of analogue outputs: 1 |
| Probe length L [mm] | 100…2000 |
| Process connection | G 3/4 external thread |
| Electrical data | |
| Operating voltage [V] | 18…30 DC |
| Current consumption [mA] | < 25 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time [s] | < 3 |
| Measuring principle | guided wave radar |
| Mechanical data | |
| Weight [g] | 486.6 |
| Materials | stainless steel (1.4301 / 304); stainless steel (1.4404 / 316L); FKM; PEI |
| Materials (wetted parts) | stainless steel (1.4305 / 303); probe connection: stainless steel (1.4435 / 316L); PTFE; FKM; Sealing: NBR reinforced fibre |
| Process connection | G 3/4 external thread |
| Electrical connection – plug | |
| Connection | Connector: 1 x M12; Contacts: gold-plated |
